AutoCAD can also be used to create navigation charts and digital maps. AutoCAD has been used for the design of wind turbines, cruise ships, power stations, cars, bridges, buildings, and many other items of construction. AutoCAD has been widely used for the design of many different kinds of machines, including factory machines. Design and documentation of building projects is the primary market for AutoCAD.Īutodesk AutoCAD is used for the design and documentation of products ranging from bicycle frames to mechanical CAD workstations. It can be accessed via a web browser on a computer or tablet.ĪutoCAD is primarily used for architectural and engineering design work, including documentation of construction projects. AutoCAD can also be used as a mobile app on iOS, Android, and Windows mobile devices. AutoCAD is available as a desktop app on the Microsoft Windows, macOS, iOS, Android, and BlackBerry operating systems. AutoCAD was first released in December 1982 and since then, the software has been repeatedly improved and updated. It was originally introduced by AutoDesk in 1982 as a desktop application running on microcomputers with internal graphics controllers. If you need help adopting Civil 3D in your practice, please contact micrographics so we can be of assistance.AutoCAD is an architectural and engineering software suite. Since this is a low-resolution surface, it is still interesting to see the crown of the road display. This is then all that is required to show the surface in cur and fill.
On the Surface properties, do an elevation analysis with two bands and a tolerance specified around zero to filter out small values. Make sure only the Elevations layer is switched on for the new surface style. Use the Volumes Dashboard to set EG as the base surface and FG as the comparison surface. The FG surface is made up of pasting the Alignment surface onto the EG surface. Shown below is the Final Grade surface (FG) and the Existing Grade surface (EG). Green for fill and red for a cut.Ĭreate a new volume surface from existing surfaces.
All that is then required is to create a surface style that displays elevations in differing colours. A positive value indicates a fill, and a negative value indicates a cut. It appears based at the zero elevation as a reference meaning no cut of fill. The cut and fill surface that is created from a cut and fill analysis is a volume surface that reports the volume difference between two surfaces. A very interesting question was posed to me: how would one display a cut and fill a surface in colour, differentiating between cut and fill with separate colours? It is easier than one would expect.
